MV 1300GB
TThe MV 1100GB is a part of the MV-B/GB Series which are 3-Axis Full BoxwayVertical Machining Center engineered & built to strict Methods specifications and quality standards. This new product line is packed with standard features and benefits that will exceed the expectations of our customers looking for quality, reliability, accuracy and longevity at a competitive price.
-
Reliable FANUC 0i-MF Control with 10.4” LCD Screen
-
Includes Manual Guide I, AICC II, 2ms BPT, and 200 Block Look Ahead
-
8,000 RPM Big Plus CAT50 Taper Gear Head Spindle with Grease Lubrication, and Ceramic Bearings,
-
Powerful 359ft-lbs of torque (30 min)
-
Prepped for 1000psi coolant thru spindle
-
Rigid Box-Way Construction in the X, Y, and Z Axes
-
Features 1181 IPM Rapid Rate in the X & Y-Axis and 945 IPM Rapid Rate in the Z-Axis
-
30 Tool ATC
-
22,000lbs machine weight
-
Thermal Compensation
-
Spindle Chiller
Travel
| X axis Travel | 51.1" (1300 mm) |
|---|---|
| Y axis Travel | 24" (610 mm) |
| Z axis Travel | 23.6" (600 mm) |
Table
| Table Dimensions | 51.2" x 23.6" (1300 x 600 mm) |
|---|---|
| Maximum Table Weight | 2,866 lbs. (1,300 kg) |
| Spindle Nose to Table Surface | 4.9” ~ 28.5” (125 mm ~ 725 mm) |
Spindle
| Spindle Speed | 8,000 rpm |
|---|---|
| Spindle Taper | Big Plus/CAT50 |
| Spindle Power | 25 HP |
| Spindle Torque | 359 ft/lb (487 Nm) |
| Spindle Lube | Oil / Air |
Feedrate
| X-Axis Rapid Traverse | 1181 in/min (30 m/min) |
|---|---|
| Y-Axis Rapid Traverse | 1181 in/min (30 m/min) |
| Z-Axis Rapid Traverse | 945 in/min (24 m/min) |
ATC
| Maximum Number of Tools | 30 |
|---|---|
| Tool-to-Tool Change Time | 2.9 sec |
| Max Diameter | 4.7 in. (120mm) OR 5.9 in. (150mm) without adjacent tool pot |
| Max Weight | 33 lbs (15 kg) |
| Max Length | 12” (305 mm) |
Dimensions/ Weight/ Capacities
| Weight | 22,000 lbs (10,000 kg) |
|---|---|
| Coolant Tank Capacity | 119 gal (450 L) |
| Control | FANUC 0i-MF |
